Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-30 2600BS-901-01 Rev. F/August 2021
bufferVar.sourcefunctions
This attribute contains the source function that was being used when the readings were stored in a specified
reading buffer.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Clearing the buffer
See Details
Not applicable
Usage
sourcefunction = bufferVar.sourcefunctions[N]
sourcefunction
The source function used (Current or Voltage) to acquire reading number N in
the specified buffer
bufferVar
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
N
The reading number (1 to bufferVar.n)
Details
The bufferVar.sourcefunctions buffer recall attribute is like an array (a Lua table) of strings
indicating the source function at the time of the measurement.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example 1
sourcefunction = smua.nvbuffer1.sourcefunctions[3]
print(sourcefunction)
Store the source function used to make reading number 3 and output the value.
Example 2
printbuffer(1, 10, smua.nvbuffer1.sourcefunctions)
Print the source function used for 10 readings stored in dedicated reading buffer 1.
Example output:
Voltage, Voltage, Voltage, Voltage, Voltage, Voltage, Voltage, Voltage, Voltage, Voltage
Also see
bufferVar.measurefunctions (on page 9-25)
bufferVar.measureranges (on page 9-26)
bufferVar.n (on page 9-28)
bufferVar.readings (on page 9-29)
bufferVar.sourceoutputstates (on page 9-31)
bufferVar.sourceranges (on page 9-31)
bufferVar.sourcevalues (on page 9-32)
bufferVar.statuses (on page 9-34)
bufferVar.timestamps (on page 9-36)
Reading buffers (on page 3-1)
