display.getcursor()
This function reads the present position of the cursor on the front-panel display.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
row, column, style = display.getcursor()
row
The row where the cursor is: 1 (top row); 2 (bottom row)
column
The column where the cursor is:
▪ If the cursor is in the top row: 1 to 20
▪ If the cursor is in the bottom row: 1 to 32
style
Visibility of the cursor:
▪ Invisible: 0
▪ Blinking: 1
Details
This function switches the front-panel display to the user screen (the text set by
display.settext()), and then returns values to indicate the row that contains the cursor and the
column position and cursor style.
Columns are numbered from left to right on the display.
Example 1
testRow, testColumn = display.getcursor()
print(testRow, testColumn)
This example reads the cursor position into local variables and prints them.
Example output:
1.00000e+00
Example 2
print(display.getcursor())
This example prints the cursor position directly. In this example, the cursor is in row 1 at column 3, with an
invisible cursor:
1.00000e+00 3.00000e+00 0.00000e+00
Also see
display.gettext() (on page 9-69)
display.screen (on page 9-78)
display.setcursor() (on page 9-80)
display.settext() (on page 9-81)
