Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-337
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 12-1) and Enable and transition registers (on page 12-19). The individual bits of
this register are defined in the following table.
status.questionable.instrument.SMUA
Set bit indicates one or more enabled bits for
the SMU A questionable register are set.
Bit B1 decimal value: 2
Binary value: 0000 0010
status.questionable.instrument.SMUB
This bit is only available on 2602B, 2604B,
2612B, 2614B, 2634B, 2636B. Set bit indicates
one or more enabled bits for the SMU B
questionable register are set.
Bit B2 decimal value: 4
Binary value: 0000 0100
As an example, to set bit B1 of the questionable status instrument summary enable register, set
status.questionable.instrument.enable = status.questionable.instrument.SMUA.
In addition to the above constants, questionableRegister can be set to the numeric equivalent of
the bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B2, set questionableRegister to 6 (which is the
sum of 2 + 4).
Example
status.questionable.instrument.enable = status.questionable.instrument.SMUA
Uses a constant to set the SMUA bit of the questionable status instrument summary enable register.
Also see
Questionable Status Registers (on page 12-13)
status.questionable.* (on page 9-333)
status.questionable.instrument.smuX.*
This attribute contains the questionable status SMU X summary register set.
