In this section:
Overview ................................................................................ 12-1
Clearing registers ................................................................. 12-14
Programming enable and transition registers ....................... 12-14
Reading registers ................................................................. 12-15
Status byte and service request (SRQ) ................................ 12-15
Status register sets .............................................................. 12-20
TSP-Link system status ....................................................... 12-25
Overview
Each Keithley Instruments 2600B provides status registers and queues that are collectively referred
to as the status model. Through manipulation and monitoring of these registers and queues, you can
view and control various instrument events. You can include commands in your test program that can
determine if a service request (SRQ) event has occurred and the cause of the event.
The heart of the status model is the Status Byte Register. All status model registers and queues flow
into the Status Byte Register.
The entire status model is illustrated in the Status model diagrams (on page 12-5).
Status register set contents
Typically, a status register set contains the following registers:
• Condition (.condition): A read-only register that is constantly updated to reflect the present
operating conditions of the instrument.
• Enable Register (.enable): A read-write register that allows a summary bit to be set when an
enabled event occurs.
• Event Register (.event): A read-only register that sets a bit to 1 when the applicable event
occurs. If the enable register bit for that event is also set, the summary bit of the register is set
to 1.
• Negative Transition Register (NTR) (.ntr): When a bit is set in this read-write register, it
enables a 1 to 0 change in the corresponding bit of the condition register to cause the
corresponding bit in the event register to be set.
• Positive Transition Register (PTR) (.ptr): When a bit is set in this read-write register, it
enables a 0 to 1 change in the corresponding bit of the condition register to cause the
corresponding bit in the event register to be set.
