Section 8: Instrument programming Series 2600B System SourceMeter® instrument Reference Manual
8-68 2600BS-901-01 Rev. F/August 2021
The following figure shows an example of the Test Script Builder. As shown, the workspace is divided
into these areas:
• Project navigator
• Script editor
• Outline view
• Programming interaction
• Help files
Figure 100: Example of the Test Script Builder workspace
Item
Description
1
Project navigator
2
Script editor; right-click to run the script that is displayed
3
Outline view
4
Programming interaction
5
Help; includes detailed information on using Test Script Builder
Project navigator
The project navigator consists of project folders and the script files (.tsp) created for each project.
Each project folder can have one or more script files.
To view the script files in a project folder, select the plus (+) symbol next to the project folder. To hide
the folder contents, select the minus (−) symbol next to the project folder.
You can download a TSP project to the instrument and run it, or you can run it from the
TSB interface.
