Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-37
Also see
bufferVar.clear() (on page 9-21)
bufferVar.collecttimestamps (on page 9-23)
bufferVar.measurefunctions (on page 9-25)
bufferVar.measureranges (on page 9-26)
bufferVar.n (on page 9-28)
bufferVar.readings (on page 9-29)
bufferVar.sourcefunctions (on page 9-30)
bufferVar.sourceoutputstates (on page 9-31)
bufferVar.sourceranges (on page 9-31)
bufferVar.sourcevalues (on page 9-32)
bufferVar.statuses (on page 9-34)
Reading buffers (on page 3-1)
ConfigPulseIMeasureV()
This KIPulse factory script function configures a current pulse train with a voltage measurement at each point.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
No
Usage
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out, sync_in_timeout, sync_in_abort)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out, sync_in_timeout)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in, sync_out)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag,
sync_in)
f, msg = ConfigPulseIMeasureV(smu, bias, level, limit, ton, toff, points, buffer, tag)
f
A Boolean flag; this flag is true when the pulse was successfully configured,
false when errors were encountered
msg
A string message; if the f flag is false, msg contains an error message; if it is
true, msg contains a string that indicates successful configuration
smu
Instrument channel (for example, smua refers to SMU channel A)
bias
Bias level in amperes
level
Pulse level in amperes
limit
Voltage limit (for example, compliance) in volts
ton
Pulse on time in seconds
toff
Pulse off time in seconds
points
Number of pulse-measure cycles
buffer
Reading buffer where pulsed measurements are stored; if this is nil when the
function is called, no measurements are made when the pulse train is initiated
tag
Numeric identifier to be assigned to the defined pulse train
sync_in
Defines a digital I/O trigger input line; if programmed, the pulse train waits for a
trigger input before executing each pulse
