Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-31
bufferVar.sourceoutputstates
This attribute indicates the state of the source output for readings that are stored in a specified buffer.
Usage
state = bufferVar.sourceoutputstates[N]
The output state (Off or On) when reading N of the specified buffer was acquired
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
The reading number (1 to bufferVar.n)
Details
The bufferVar.sourceoutputstates buffer recall attribute is similar to an array (a Lua table) of
strings. This array indicates the state of the source output (Off or On) at the time of the
measurement.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example
printbuffer(1, 1, smua.nvbuffer1.sourceoutputstates)
Print the source output for the first reading stored in dedicated reading buffer 1.
Example output:
On
Also see
bufferVar.measurefunctions (on page 9-25)
bufferVar.measureranges (on page 9-26)
bufferVar.n (on page 9-28)
bufferVar.readings (on page 9-29)
bufferVar.sourcefunctions (on page 9-30)
bufferVar.sourceranges (on page 9-31)
bufferVar.sourcevalues (on page 9-32)
bufferVar.statuses (on page 9-34)
bufferVar.timestamps (on page 9-36)
Reading buffers (on page 3-1)
bufferVar.sourceranges
This attribute contains the source range that was used for readings stored in a specified reading buffer.
