Series 2600B System SourceMeter® instrument Reference Manual Section 7: Introduction to TSP operation
2600BS-901-01 Rev. F/August 2021 7-23
Conditions that must be true for successful function execution
Conditions for Config functions
Conditions for InitiatePulseTest
functions
Conditions for InitiatePulseTestDual
functions
Source autorange (I and V) off
Output on
Output on
Measure autorange (I and V) off
There is enough free space in the
buffer
There is enough free space in the
buffer
Measure NPLC < ton
Buffer append mode is on when
pulse train is >1 point
Buffer append mode is on when pulse
train is >1 point
Measure autozero OFF or ONCE
Safety interlock engaged when
using the 200 V range
Separate unique source-measure units
(SMUs) for each tag
Safety interlock engaged when using
the 200 V range
Same NPLC setting for each tag
Same toff for each tag
Use the KIPulse simple pulse functions (on page 7-23) to specify and perform a specified number of
pulse-measure cycles.
KIPulse tag parameter pulse functions
ConfigPulseIMeasureV() (on page 9-37)
ConfigPulseVMeasureI() (on page 9-43)
ConfigPulseIMeasureVSweepLin() (on page 9-39)
ConfigPulseVMeasureISweepLin() (on page 9-45)
ConfigPulseIMeasureVSweepLog() (on page 9-41)
ConfigPulseVMeasureISweepLog() (on page 9-47)
InitiatePulseTest() (on page 9-113)
InitiatePulseTestDual() (on page 9-115)
QueryPulseConfig() (on page 9-175)
KIPulse simple pulse functions
PulseIMeasureV() (on page 9-173)
PulseVMeasureI() (on page 9-174)
Advanced features for KIPulse tag parameter pulse functions
Variable off time between pulses in a pulse train
The KIPulse “Configure” functions accept the toff parameter as a table or as a number. The table
allows you to define different off times to be used after each pulse. Note the following:
• If toff is passed as a number or only a single value is used in the table, it is used for all points in
a multiple point pulse.
• The number of times specified in the table must match the number of points called for in
the sweep.
• The times used in tables must match for dual channel pulsing.
• Each specified off time must adhere to the duty cycle limits for the specified pulsing region.
