Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-341
Also see
Questionable Status Registers (on page 12-13)
status.questionable.* (on page 9-333)
status.questionable.unstable_output.*
This attribute contains the questionable status unstable output summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2601B, 2611B, 2635B: 2 (All bits set)
2602B, 2604B, 2612B, 2614B, 2634B,
2636B: 6 (All bits set)
Usage
questionableRegister = status.questionable.unstable_output.condition
questionableRegister = status.questionable.unstable_output.enable
questionableRegister = status.questionable.unstable_output.event
questionableRegister = status.questionable.unstable_output.ntr
questionableRegister = status.questionable.unstable_output.ptr
status.questionable.unstable_output.enable = questionableRegister
status.questionable.unstable_output.ntr = questionableRegister
status.questionable.unstable_output.ptr = questionableRegister
operationRegister
The status of the questionable status unstable output summary
register; a zero (0) indicates no bits set (also send 0 to clear all
bits); other values indicate various bit settings
Details
These attributes are used to read or write to the questionable status unstable output summary
registers. Reading a status register returns a value. The binary equivalent of the returned value
indicates which register bits are set. The least significant bit of the binary number is bit B0, and the
most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 12-1) and Enable and transition registers (on page 12-19). The individual bits of
this register are defined in the following table.
Bit
Value
Description
B0
Not used
Not applicable.
B1
status.questionable.unstable_output.SMUA
Set bit indicates that an unstable output
condition was detected on SMU A.
Bit B1 decimal value: 2
Binary value: 0000 0010
