Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-324 2600BS-901-01 Rev. F/August 2021
Example 1
status.operation.instrument.tsplink.trigger_overrun.enable =
status.operation.instrument.tsplink.trigger_overrun.LINE1
Uses a constant to set the line 1 bit of the operation status TSP-Link overrun enable register.
Example 2
status.operation.instrument.tsplink.trigger_overrun.enable = 10
Uses the decimal value to set bits for lines 1 and 3 of the operation status TSP-Link overrun enable register.
Also see
Operation Status Registers (on page 12-8)
status.operation.instrument.trigger_timer.* (on page 9-318)
status.operation.measuring.*
This attribute contains the operation status measuring summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2601B, 2611B, 2635B:
2 (All bits set)
2602B, 2604B, 2612B, 2614B,
2634B, 2636B:
6 (All bits set)
Usage
operationRegister = status.operation.measuring.condition
operationRegister = status.operation.measuring.enable
operationRegister = status.operation.measuring.event
operationRegister = status.operation.measuring.ntr
operationRegister = status.operation.measuring.ptr
status.operation.measuring.enable = operationRegister
status.operation.measuring.ntr = operationRegister
status.operation.measuring.ptr = operationRegister
operationRegister
The status of the operation status measuring summary register; a zero (0) indicates
no bits set (also send 0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the operation status measuring summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 12-1) and Enable and transition registers (on page 12-19). The individual bits of
this register are defined in the following table.
