Section 2: Sourcing and measuring Series 2600B System SourceMeter® instrument Reference Manual
2-52 2600BS-901-01 Rev. F/August 2021
Figure 22: DC and pulsed list sweeps
Sweep characteristics
For any of the sweep types, program a pulse sweep by configuring the end pulse action. Refer to
Pulse mode sweeps (on page 2-58) for more information.
Linear staircase sweeps
As shown below, this sweep type steps from a start voltage or current value to an ending (stop) value.
When enabled, a measurement is made at each point after the source and measurement settling
time.
Figure 23: Linear staircase sweep
