Section 8: Instrument programming Series 2600B System SourceMeter® instrument Reference Manual
8-20 2600BS-901-01 Rev. F/August 2021
Group commands using the function keyword
The following script contains instrument commands that display the name of the person that is using
the script on the front panel of the instrument. It takes one parameter to represent this name. When
this script is run, the function is loaded in memory. Once loaded into memory, you can call the
function outside of the script to execute it.
When calling the function, you must specify a string for the name argument of the function. For
example, to set the name to John, call the function as follows:
myDisplay("John")
Example: User script
User script created in Test Script Builder or
TSB Embedded
User script created in a different program
function myDisplay(name)
display.clear()
display.settext(
name .. "$N is here!")
end
loadscript
function myDisplay(name)
display.clear()
display.settext(
name .. " $N is here!")
end
endscript
Operators
You can compare and manipulate Lua variables and constants using operators.
Arithmetic operators
Operator
Description
+
addition
-
subtraction
*
multiplication
/
division
-
negation (for example, c = −a)
^
exponentiation
Relational operators
Operator
Description
<
less than
>
greater than
<=
less than or equal
>=
greater than or equal
~=
not equal
==
equal
