Section 2: Sourcing and measuring Series 2600B System SourceMeter® instrument Reference Manual
2-64 2600BS-901-01 Rev. F/August 2021
Linear staircase sweep example
The programming example below illustrates a staircase sweep.
-- Restore 2600B defaults.
smua.reset()
-- Set compliance to 1 V.
smua.source.limitv = 1
1. Configure source functions.
Restores defaults and sets the
compliance limit to 1 V.
-- Linear staircase sweep
-- 1 mA to 10 mA, 0.1 second delay,
-- 10 points.
SweepILinMeasureV(smua, 1e-3, 10e-3, 0.1, 10)
2. Configure and execute the sweep.
Configures a linear staircase current
sweep from 1 mA to 10 mA with 10
points and a 0.1 second settling time.
printbuffer(1, 10, smua.nvbuffer1.readings)
3. Request readings.
Requests readings from buffer 1.
Pulse current sweep example
The programming example below illustrates a pulse sweep.
-- Restore 2600B defaults.
smua.reset()
-- Set compliance to 10 V.
smua.source.limitv = 10
1. Configure source functions.
Restores defaults and sets the
compliance to 10 V.
-- Pulse current sweep, 1 mA bias,
-- 10 mA level, 10 ms pulse on,
-- 50 ms pulse off, 10 cycles.
PulseIMeasureV(smua, 1e-3, 10e-3, 20e-3, 50e-3, 10)
2. Configure and execute the sweep.
Configures a 10 mA pulse current
sweep with a 10 ms pulse on time, a
50 ms pulse off time, and 10
pulse-measure cycles.
printbuffer(1, 10, smua.nvbuffer1.readings)
3. Request readings.
Requests readings from buffer 1.
List sweep example
The programming example below illustrates a list sweep.
-- Restore 2600B defaults.
smua.reset()
-- Set compliance to 10 mA.
smua.source.limiti = 10e-3
1. Configure source functions.
Restores defaults and set the
compliance to 10 mA.
-- Define voltage list.
vlist = {3, 1, 4, 5, 2}
-- List sweep, channel A, 3 V, 1 V, 4 V,
-- 5 V, 2 V steps, 0.1 s delay, 5 points.
SweepVListMeasureI(smua, vlist, 0.1, 5)
2. Configure and execute the sweep.
Configures a list sweep with 3 V, 1 V,
4 V, 5 V, and 2 V points using a 0.1
second settling time.
printbuffer(1, 5, smua.nvbuffer1.readings)
3. Request readings.
Requests readings from buffer 1.
