Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-240 2600BS-901-01 Rev. F/August 2021
smuX.source.compliance
This attribute contains the state of source compliance.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Not applicable
Not saved
Not applicable
Usage
compliance = smuX.source.compliance
compliance
The state of source compliance:
▪ true: Indicates that the limit function is in control of the source (source in
compliance)
▪ false: Indicates that the source function is in control of the output (source
not in compliance)
X
Source-measure unit (SMU) channel (for example, smua.source.compliance
applies to SMU channel A)
Details
Reading this attribute updates the status model and the front panel with generated compliance
information. See Current Limit (ILMT) in the status model diagram for the Measurement event
registers (on page 12-7). The Voltage Limit (VLMT) is not shown in the status model diagram for the
Measurement event registers but is similar to the Current Limit (ILMT).
Example
compliance = smua.source.compliance
print(compliance)
Reads the source compliance state for SMU channel A.
Output:
true
This output indicates that a configured limit has been reached (voltage, current, or power limit).
Also see
smuX.source.limitY (on page 9-244)
