To import a script from the host computer:
1. Select Import from PC.
2. Choose Select File to select a file. You can also drag the file into the Select File box.
3. Select Import.
4. In the TSP Script box, modify the script name as needed.
5. Select Save Script.
The script is added to the User Scripts list.
Export a script to a computer
You can download a script from TSB Embedded to the host computer.
TSP scripts have the extension .tsp.
To export a script to a computer:
1. Select the script from the User Scripts list.
2. Select Export to PC. The file is saved as a download.
3. Use the procedure for your browser to work with file.
Export a script to the instrument USB
You can save a script to the USB drive on the front panel of the instrument.
To export a script to the instrument USB drive:
1. Insert a flash drive into the USB on the front panel of the instrument.
2. Select the script from the User Scripts list.
3. In the Export File Name box, enter
4. Select Export to USB.
5. Enter the Export File Name.
6. Select Export.
Reset the instrument using TSB Embedded
The reset option in TSB Embedded performs an abort followed by a reset().
Refer to reset() (on page 9-177) for additional information.
