Output-off limits (compliance)
You can set output-off limits (compliance) for the current and voltage output-off functions using the
CONFIG menu on the 2600B front panel, or by setting the smuX.source.offlimitY attribute from
a remote interface. The output-off limits only apply when the output-off mode is normal.
Setting output-off limits
Setting the output-off limit for CURRENT (smuX.source.offlimiti) specifies the current limit for
the voltage source; setting the output-off limit for VOLTAGE (smuX.source.offlimitv) specifies
the voltage limit for the current source.
To configure the output-off limits from the front panel:
1. Press the CONFIG key.
2. Press the OUTPUT ON/OFF control.
3. Select OFF-STATE and then select LIMIT.
4. Select CURRENT or VOLTAGE.
5. Set the limit value and then press the ENTER key or the navigation wheel.
6. Press the EXIT key to return to the normal display.
To set the current limit in NORMAL output-off mode remotely:*
smuX.source.offlimiti = iValue
To set the voltage limit in NORMAL output-off mode remotely:*
smuX.source.offlimitv = vValue
* smuX can be smua for channel A or smub for channel B
Remote programming output-off states quick reference
The content of the following table is a quick reference of commands for programming output-off states
from a remote interface.
