Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-262 2600BS-901-01 Rev. F/August 2021
Trigger event IDs*
Event ID
Event description
* Use the name of the trigger event ID to set the stimulus value rather than the numeric value. Using the name makes the
code compatible for future upgrades (for example, if the numeric values must change when enhancements are added to the
instrument).
Example
smua.trigger.endpulse.action = smua.SOURCE_IDLE
smua.trigger.endpulse.stimulus = trigger.timer[1].EVENT_ID
Configure the end pulse action to achieve a pulse and select the event, trigger.timer[1].EVENT_ID, that
causes the arm event detector to enter the detected state.
Also see
Triggering (on page 4-1)
smuX.trigger.endsweep.action
This attribute sets the action of the source at the end of a sweep.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0 (smuX.SOURCE_IDLE)
Usage
action = smuX.trigger.endsweep.action
smuX.trigger.endsweep.action = action
action
The source action at the end of a sweep; set to one of the following values:
▪ 0 or smuX.SOURCE_IDLE: Sets the source level to the programmed (idle)
level at the end of the sweep
▪ 1 or smuX.SOURCE_HOLD: Sets the source level to stay at the level of the
last step
X
Source-measure unit (SMU) channel (for example,
smua.trigger.endsweep.action applies to SMU channel A)
Details
Use this attribute to configure the source action at the end of the sweep. The SMU can be
programmed to return to the idle source level or hold the last value of the sweep.
Example
smua.trigger.endsweep.action = smua.SOURCE_IDLE
Sets SMU channel A to return the source back to the idle source level at the end of a sweep.
Also see
Triggering (on page 4-1)
