Figure 86: 2602B and 2612B IEEE-488, LAN, USB, and RS-232 connections (2601B, 2604B,
2611B, and 2614B similar)
1 IEEE-488 connection
2 LAN connection
3 USB connection
4 RS-232 connection
Figure 87: 2636B IEEE-488, LAN, USB, and RS-232 connections (2634B and 2635B similar)
1 IEEE-488 connection
2 LAN connection
3 USB connection
4 RS-232 connection
