Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference

2600BS-901-01 Rev. F/August 2021 9-27

Usage

measurerange = bufferVar.measureranges[N]

measurerange

The measurement range used to acquire reading number N in the specified buffer

bufferVar

The reading buffer; can be a dynamically allocated buffer (user-defined), or a

dedicated reading buffer (such as smua.nvbuffer1)

The reading number (1 to bufferVar.n)

Details

The measureranges buffer recall attribute is like an array (a Lua table) of full-scale range values for

the measure range used when the measurement was made.

For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the

reading buffer is saved to nonvolatile memory.

Example 1

measurerange = smua.nvbuffer1.measureranges[1]

Store the measure range that was used to make reading number 1.

Example 2

printbuffer(1, 10, smua.nvbuffer1.measureranges)

Print the range values that were used for the first 10 readings saved in dedicated reading buffer 1.

Example output:

1.00000e-07, 1.00000e-07,

1.00000e-07, 1.00000e-07

Also see

bufferVar.measurefunctions (on page 9-25)

bufferVar.n (on page 9-28)

bufferVar.readings (on page 9-29)

bufferVar.sourcefunctions (on page 9-30)

bufferVar.sourceoutputstates (on page 9-31)

bufferVar.sourceranges (on page 9-31)

bufferVar.sourcevalues (on page 9-32)

bufferVar.statuses (on page 9-34)

bufferVar.timestamps (on page 9-36)

Reading buffers (on page 3-1)
