Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual

9-114 2600BS-901-01 Rev. F/August 2021

Example

smua.reset()

smua.source.rangev = 5

smua.source.rangei = 1

smua.source.levelv = 0

smua.measure.rangev = 5

smua.measure.rangei = 1

smua.measure.nplc = 0.01

smua.measure.autozero = smua.AUTOZERO_ONCE

smua.nvbuffer1.clear()

smua.nvbuffer1.appendmode = 1

smua.source.output = smua.OUTPUT_ON

f1, msg1 = ConfigPulseVMeasureI(smua, 0, 5, 1, 0.002, 0.2, 10, smua.nvbuffer1, 1)

if f1 == true then

f2, msg2 = InitiatePulseTest(1)

print("Initiate message:", msg2)

else

print("Config errors:", msg1)

end

Configure channel A to generate a pulse train. If no errors are encountered, initiate the pulse train. Channel A

pulses voltage from a bias level of 0 V to a pulse level of 5 V. The pulse level is present for 2 ms and the bias

level for 200 ms, with a 1 A limit setting. A total of 10 pulses is generated, and the measurement data is stored

in smua.nvbuffer1. This pulse train is assigned to tag = 1.

Also see

ConfigPulseIMeasureV() (on page 9-37)

ConfigPulseIMeasureVSweepLin() (on page 9-39)

ConfigPulseIMeasureVSweepLog() (on page 9-41)

ConfigPulseVMeasureI() (on page 9-43)

ConfigPulseVMeasureISweepLin() (on page 9-45)

ConfigPulseVMeasureISweepLog() (on page 9-47)

KIPulse factory script (on page 7-22)
