Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-283
Bit
Value
Description
B0
status.measurement.VOLTAGE_LIMIT
status.measurement.VLMT
Set bit is a summary of the
status.measurement.voltage_limit
register.
Bit B0 decimal value: 1
B1
status.measurement.CURRENT_LIMIT
status.measurement.ILMT
Set bit is a summary of the
status.measurement.current_limit
register.
Bit B1 decimal value: 2
B2 to B6
Not used
Not applicable
B7
status.measurement.READING_OVERFLOW
status.measurement.ROF
Set bit is a summary of the
status.measurement.reading_overflow
register.
Bit B7 decimal value: 128
B8
status.measurement.BUFFER_AVAILABLE
status.measurement.BAV
Set bit is a summary of the
status.measurement.buffer_available
register.
Bit B8 decimal value: 256
B9 to B10
Not used
Not applicable
B11
status.measurement.OUTPUT_ENABLE
status.measurement.OE
2601B, 2602B, 2604B: output enable line. Set
bit indicates that output enable has been
asserted.
Bit B11 decimal value: 2,048
status.measurement.INTERLOCK
status.measurement.INT
2611B, 2612B, 2614B, 2634B, 2635B, 2636B:
interlock line. Set bit indicates that interlock has
been asserted.
Bit B11 decimal value: 2,048
B12
Not used
Not applicable
B13
status.measurement.INSTRUMENT_SUMMARY
status.measurement.INST
Set bit indicates that a bit in the measurement
instrument summary register is set.
Bit B13 decimal value: 8,192
B14 to B15
Not used
Not applicable
As an example, to set bit B8 of the measurement event enable register, set
status.measurement.enable = status.measurement.BAV.
In addition to the above constants, measurementRegister can be set to the decimal equivalent of
the bit to set. To set more than one bit of the register, set measurementRegister to the sum of
their decimal weights. For example, to set bits B1 and B8, set measurementRegister to 258
(which is the sum of 2 + 256).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
