Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-302 2600BS-901-01 Rev. F/August 2021
Bit
Value
Description
B0
Not used
Not applicable.
B1
status.operation.instrument.SMUA
Set bit indicates one or more enabled
bits for the operation status SMU A
summary register is set.
Bit B1 decimal value: 2
B2
status.operation.instrument.SMUB
This bit is only available on 2602B,
2604B, 2612B, 2614B, 2634B, 2636B.
Set bit indicates one or more enabled
bits for the operation status SMU B
summary register is set.
Bit B2 decimal value: 4
B3 to B9
Not used
Not applicable.
B10
status.operation.instrument.TRIGGER_BLENDER
status.operation.instrument.TRGBLND
Set bit indicates one or more enabled
bits for the operation status trigger
blender summary register is set.
Bit B10 decimal value: 1,024.
B11
status.operation.instrument.TRIGGER_TIMER
status.operation.instrument.TRGTMR
Set bit indicates one or more enabled
bits for the operation status trigger
timer summary register is set.
Bit B11 decimal value: 2,048
B12
status.operation.instrument.DIGITAL_IO
status.operation.instrument.DIGIO
This bit is only available on 2601B,
2602B, 2611B, 2612B, 2635B, 2636B.
Set bit indicates one or more enabled
bits for the operation status digital I/O
summary register is set.
Bit B12 decimal value: 4,096
B13
status.operation.instrument.TSPLINK
This bit is only available on 2601B,
2602B, 2611B, 2612B, 2635B, 2636B.
Set bit indicates one or more enabled
bits for the operation status TSP-Link
summary register is set.
Bit B13 decimal value: 8,192
B14
status.operation.instrument.LAN
Set bit indicates one or more enabled
bits for the operation status LAN
summary register is set.
Bit B14 decimal value: 16,384
B15
Not used
Not applicable.
As an example, to set bit B1 of the operation status instrument summary enable register, set
status.operation.instrument.enable = status.operation.instrument.SMUA.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B10, set operationRegister to 1,026 (which is
the sum of 2 + 1,024).
