Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-310 2600BS-901-01 Rev. F/August 2021
Bit
Value
Decimal value
B0
Not used
Not applicable
B1
status.operation.instrument.lan.trigger_overrun.LAN1
2
B2
status.operation.instrument.lan.trigger_overrun.LAN2
4
B3
status.operation.instrument.lan.trigger_overrun.LAN3
8
B4
status.operation.instrument.lan.trigger_overrun.LAN4
16
B5
status.operation.instrument.lan.trigger_overrun.LAN5
32
B6
status.operation.instrument.lan.trigger_overrun.LAN6
64
B7
status.operation.instrument.lan.trigger_overrun.LAN7
128
B8
status.operation.instrument.lan.trigger_overrun.LAN8
256
B9 to B15
Not used
Not applicable
As an example, to set bit B1 of the operation status LAN trigger overrun enable register, set
status.operation.instrument.lan.trigger_overrun.enable =
status.operation.instrument.lan.trigger_overrun.LAN1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B8, set operationRegister to 258 (which is the
sum of 2 + 256).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
operationRegister = status.operation.instrument.lan.trigger_overrun.LAN1 +
status.operation.instrument.lan.trigger_overrun.LAN8
status.operation.instrument.lan.trigger_overrun.enable = operationRegister
Use constants to set bit B1 and bit B8 of the operation status LAN trigger overrun enable register.
Example 2
operationRegister = 258
status.operation.instrument.lan.trigger_overrun.enable = operationRegister
Use the decimal value to set bit B1 and bit B8 of the operation status LAN trigger overrun enable register.
Also see
Operation Status Registers (on page 12-8)
status.operation.instrument.lan.* (on page 9-307)
