Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-314 2600BS-901-01 Rev. F/August 2021
Bit
Value and description
B2
status.operation.instrument.smuX.trigger_overrun.SRC
Set bit indicates that the source event detector of the SMU was already in the detected state
when a trigger was received.
Bit B2 decimal value: 4
B3
status.operation.instrument.smuX.trigger_overrun.MEAS
Set bit indicates that the measurement event detector of the SMU was already in the detected
state when a trigger was received.
Bit B3 decimal value: 8
B4
status.operation.instrument.smuX.trigger_overrun.ENDP
Set bit indicates that the end pulse event detector of the SMU was already in the detected state
when a trigger was received.
Bit B4 decimal value: 16
B5 to B15
Not used
As an example, to set bit B1 of the operation status SMU A trigger overrun enable register, set
status.operation.instrument.smua.trigger_overrun.enable =
status.operation.instrument.smua.trigger_overrun.ARM.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B4, set operationRegister to 18 (which is the
sum of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
status.operation.instrument.smua.trigger_overrun.enable =
status.operation.instrument.smua.trigger_overrun.ARM
Uses a constant to sets the ARM bit of the operation status SMU A trigger overrun enable register.
Example 2
status.operation.instrument.smua.trigger_overrun.enable = 18
Uses the decimal value to set bits B1 and B4 of the operation status SMU A trigger overrun enable register.
Also see
Operation Status Registers (on page 12-8)
status.operation.instrument.smuX.* (on page 9-311)
