For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 12-1) and Enable and transition registers (on page 12-19). The individual bits of
this register are defined in the following table.
Bit
Value
Decimal value
B0
Not used
Not applicable
B1
status.operation.instrument.trigger_blender.trigger_overrun.BLND1
2
B2
status.operation.instrument.trigger_blender.trigger_overrun.BLND2
4
B3
status.operation.instrument.trigger_blender.trigger_overrun.BLND3
8
B4
status.operation.instrument.trigger_blender.trigger_overrun.BLND4
16
B5
status.operation.instrument.trigger_blender.trigger_overrun.BLND5
32
B6
status.operation.instrument.trigger_blender.trigger_overrun.BLND6
64
B7 to
B15
Not used
Not applicable
As an example, to set bit B1 of the operation status trigger blender overrun enable register, set
status.operation.instrument.trigger_blender.trigger_overrun.enable =
status.operation.instrument.trigger_blender.trigger_overrun.BLND1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B4, set operationRegister to 18 (which is the
sum of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example
status.operation.instrument.trigger_blender.trigger_overrun.enable
= status.operation.instrument.trigger_blender.trigger_overrun.BLND1
Uses the constant to set the bit for blender 1 of the operation status trigger blender overrun enable register.
Example
status.operation.instrument.trigger_blender.trigger_overrun.enable = 18
Uses the decimal value to set the bits for blenders 1 and 4 of the operation status trigger blender overrun
enable register.
Also see
Operation Status Registers (on page 12-8)
status.operation.instrument.trigger_blender.* (on page 9-315)
