Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-332 2600BS-901-01 Rev. F/August 2021
Bit
Value
Decimal value
B5
status.operation.user.BIT5
32
B6
status.operation.user.BIT6
64
B7
status.operation.user.BIT7
128
B8
status.operation.user.BIT8
256
B9
status.operation.user.BIT9
512
B10
status.operation.user.BIT10
1,024
B11
status.operation.user.BIT11
2,048
B12
status.operation.user.BIT12
4,096
B13
status.operation.user.BIT13
8,192
B14
status.operation.user.BIT14
16,384
B15
Not used
Not applicable
As an example, to set bit B0 of the operation status user enable register, set
status.operation.user.enable = status.operation.user.BIT0.
In addition to the above constants, operationRegister can be set to the decimal value of the bit to
set. To set more than one bit of the register, set operationRegister to the sum of their decimal
values. For example, to set bits B11 and B14, set operationRegister to 18,432 (which is the sum
of 2,048 + 16,384).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
operationRegister = status.operation.user.BIT11 + status.operation.user.BIT14
status.operation.user.enable = operationRegister
Uses constants to set bits B11 and B14 of the operation status user enable register.
Example 2
-- 18432 = binary 0100 1000 0000 0000
operationRegister = 18432
status.operation.enable = operationRegister
Uses the decimal value to set bits B11 and B14 of the operation status user enable register.
Also see
Operation Status Registers (on page 12-8)
status.operation.* (on page 9-297)
