Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-350 2600BS-901-01 Rev. F/August 2021
Bit
Value
Decimal value
B0
status.system.EXTENSION_BIT
status.system.EXT
1
B1
status.system.NODE1
2
B2
status.system.NODE2
4
B3
status.system.NODE3
8
B4
status.system.NODE4
16
B5
status.system.NODE5
32
B6
status.system.NODE6
64
B7
status.system.NODE7
128
B8
status.system.NODE8
256
B9
status.system.NODE9
512
B10
status.system.NODE10
1,024
B11
status.system.NODE11
2,048
B12
status.system.NODE12
4,096
B13
status.system.NODE13
8,192
B14
status.system.NODE14
16,384
B15
Not used
Not applicable
As an example, to set bit B0 of the system summary status enable register, set
status.system.enable = status.system.enable.EXT.
In addition to the above constants, enableRegister can be set to the decimal value of the bit to
set. To set more than one bit of the register, set enableRegister to the sum of their decimal
values. For example, to set bits B11 and B14, set enableRegister to 18,432 (which is the sum of
2,048 + 16,384).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
enableRegister = status.system.NODE11 + status.system.NODE14
status.system.enable = enableRegister
Uses constants to set bits B11 and B14 of the system summary enable register.
