Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-358 2600BS-901-01 Rev. F/August 2021
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 12-1) and Enable and transition registers (on page 12-19). The individual bits of
this register are defined in the following table.
Bit
Value
Decimal value
B0
Not used
Not applicable
B1
status.system5.NODE57
2
B2
status.system5.NODE58
4
B3
status.system5.NODE59
8
B4
status.system5.NODE60
16
B5
status.system5.NODE61
32
B6
status.system5.NODE62
64
B7
status.system5.NODE63
128
B8
status.system5.NODE64
256
B9 to B15
Not used
Not applicable
As an example, to set bit B1 of the system summary 5 enable register, set
status.system5.enable = status.system5.NODE57.
In addition to the above constants, enableRegister can be set to the numeric equivalent of the bit
to set. To set more than one bit of the register, set enableRegister to the sum of their decimal
weights. For example, to set bits B1 and B4, set enableRegister to 18 (which is the sum
of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
enableRegister = status.system5.NODE57 + status.system5.NODE60
status.system2.enable = enableRegister
Uses constants to set bits B1 and B4 of the system summary 5 enable register.
Example 2
-- decimal 18 = binary 0000 0000 0001 0010
enableRegister = 18
status.system5.enable = enableRegister
Uses the decimal value to set bits B1 and B4 of the system summary 5 enable register.
