Series 2600B System SourceMeter® instrument Reference Manual Section 10: Calibration
2600BS-901-01 Rev. F/August 2021 10-13
2. Set the multimeter measuring function to dc volts.
3. On a two-channel instrument (2602B, 2604B, 2612B, 2614B, 2634B, or 2636B), select the
single-channel display mode.
4. Press the SRC key to source voltage and make sure the source output is turned on.
5. Enable the 2600B 4-wire (remote sense) mode:
a. Press the CONFIG key and then the SRC key.
b. Select V-SOURCE > SENSE-MODE > 4-WIRE.
6. Verify output voltage accuracy for each of the voltages listed in the following table for your model
number. For each test point:
▪ Select the correct source range.
▪ Set the 2600B output voltage to the indicated value.
▪ Verify that the multimeter reading is within the limits given in the table.
2601B, 2602B, 2604B output voltage accuracy limits
Source range
Output voltage setting
Output voltage limits
(1 year, 18 °C to 28 °C)
100 mV
1 V
6 V
40 V
90.000 mV
0.90000 V
5.4000 V
36.000 V
89.732 mV to 90.268 mV
0.89942 V to 0.90058 V
5.39712 V to 5.40288 V
35.9808 V to 36.0192 V
2611B, 2612B, 2614B, 2634B, 2635B, 2636B output voltage accuracy
limits
Source range
Output voltage setting
Output voltage limits
(1 year, 18 °C to 28 °C)
200 mV
2 V
20 V
200 V
180.000 mV
1.80000 V
18.000 V
180.000 V
179.589 mV to 180.411 mV
1.79904 V to 1.80096 V
17.9914 V to 18.0086 V
179.914 V to 180.086 V
7. Repeat the procedure for negative output voltages with the same magnitudes as those listed in
the previous table, as applicable.
8. For a two-channel instrument (2602B, 2604B, 2612B, 2614B, 2634B, or 2636B), repeat the
procedure for the other channel.
