Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
416
Firmware Version 3/4.31.37
Type
Inputs
Description
Set/Reset
A.) Custom Logic Index
B.) Custom Logic Index
If the output is 0 and input A is set to 1 then the
output will be set to 1. If the output is 1 and input B is
set to 1, then the output will be reset to 0.
- Input A is the set.
- Input B is the reset.
13.2.7 SCALING
The Scaling group gives you the ability to take an input and output a percentage based on a specified minimum
and a maximum range,
First select a custom logic line that will be the absolute minimum of the range. Second select a custom logic line
that will be the absolute maximum. The last custom logic line selection will be the input, which will be used to
calculate a percentage. The output will be a percentage ranging from %0.00 to %100.00 with an implied decimal.
Input
Description
A.) Custom Logic Index
Absolute minimum
B.) Custom Logic Index
Absolute Maximum
C.) Custom Logic Index
Input variable
13.2.8 RANGE CHECKING
The Range Checking group gives you the ability to check whether or not a custom logic line’s value is within a
specified range.
SELECT CUSTOM LOGIC SCALING
SCALE 0 TO 100%
Next Prev Exit Enter
