Toptech Systems MultiLoad II User Manual

Chapter 10– Views and Inquiries
333
Firmware Version 3/4.31.37
Use the CLR key to zero out the resettable totalizers.
10.4 VIEWING TEMPERATURES
From the Views and Inquiry Menu select Temperature. After selecting the preset and meter, the Temperature
screen displays:
Parameter Descriptions:
Temperature Input
Displays the live value that is being read by the input. It will display ohms for RTD, or mA
for an analog input.
Temp Unadjusted
Displays the RTD real-time temperature.
Temp Offset
Displays the current temperature offset value, which is the difference between the Temp
Unadjusted value and the Temp Adjusted (observed temperature) value.
Temp Adjusted
Displays the observed temperature as a result of applying the temperature offset.
10.5 VIEWING PRESSURES
From the Views and Inquiry Menu select Pressure. After selecting the preset and meter, the Pressure screen
displays:
PRE #1 MTR #1 TEMPERATURE
Temperature Input: 099.417Ω
Temperature Unadjusted: -1.49C
[1]Temperature Offset: +0.00C
[2]Temperature Adjusted: -1.49C
Status Ok
Next Prev Exit
