Toptech Systems MultiLoad II User Manual

Chapter 10– Views and Inquiries
336
Firmware Version 3/4.31.37
10.8 VIEWING BSW1
From the Views and Inquiry Menu select BSW1. After selecting the preset, the BSW1 screen displays:
Parameter Descriptions:
BSW1 Input
Displays the live mA value that is being read by the analog input.
BSW1 Unadjusted
Displays the real-time BSW1.
BSW1 Offset
Displays the current BSW1 offset value, which is the difference between the
BSW1 Unadjusted value and the BSW1 Adjusted (observed relative density)
value.
BSW1 Adjusted
Displays the observed BSW1 as a result of applying the BSW1 offset.
10.9 VIEWING BSW2
From the Views and Inquiry Menu select BSW2. After selecting the preset, the BSW2 screen displays:
PRE #1 BSW1
BSW1 Input: 08.000mA
BSW1 Unadjusted: +25.00%
[1]BSW1 Offset: +0.00%
[2]BSW1 Adjusted: +25.00%
Next Prev Exit
