Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
385
Firmware Version 3/4.31.37
Once authorized, the End Sampler Batch screen will be displayed with a picklist of all the configured sample pots.
CHAPTER 13 CUSTOM LOGIC
13.1 OVERVIEW
Custom Logic supplements the standard logic in MultiLoad II. This allows the MultiLoad II to perform many of the
simple I/O sequencing tasks that would have required an additional PLC.
Configuring Custom Logic involves building a list of logic instructions to read FCM inputs, read MultiLoad II
internal states (bay authorized, batch authorized, pump run, etc.), perform logic operations (logic AND, OR, etc.),
control FCM outputs, create timers, and send email messages.
To access the Custom Configuration from the MultiLoad II keypad, enter the program mode, select Configuration,
then Custom Logic. The Custom Logic screen displays.
END SAMPLER BATCH
Sampler 01
Sampler 02
Sampler 03
Sampler 04
Next Prev Exit Enter
END SAMPLER BATCH
Enter Driver Number:_
Next Prev Exit Enter
