Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
417
Firmware Version 3/4.31.37
First select a custom logic line that will be the absolute minimum of the range. Second select a custom logic line
that will be the absolute maximum. The last custom logic line selection will be the input, which will be checked to
see if it is greater than the minimum and less than the maximum. If it is within range then the output will be a 1,
otherwise the output will be 0.
Input
Description
A.) Custom Logic Index
Absolute minimum
B.) Custom Logic Index
Absolute Maximum
C.) Custom Logic Index
Input variable
13.2.9 REAL TIME TOTALIZERS
The Real Time Totalizers group gives you the ability to assign a specific Preset, Meter, Component, Additive, or
Sampler totalizer to a custom logic line and the values are updated in real time. The ones that are labeled RTOT
represent resettable totalizers.
SELECT CUSTOM LOGIC TYPE PARAMETER
PRESET R.T. TOT.
METER R.T. TOT.
COMP. R.T. TOT.
ADDI. R.T. TOT.
SAMP. R.T. TOT.
PRESET R.T.RTOT
METER R.T. RTOT
COMP. R.T. RTOT
ADDI. R.T. RTOT
SAMP. R.T. RTOT
Next Prev Exit Enter
SELECT CUSTOM LOGIC RANGE PARAMETER
RANGE CHECK
Next Prev Exit Enter
