In the example above, the MultiLoad sent a read 32-bit command to read register 12000 from Device #1, and the
device returned a value of 65535.
8.26 GPS DIAGNOSTICS (MULTILOAD II MOBLE ONLY)
GPS diagnostics displays the current detailed status of the connected GPS.
UTC Date
The current Universal Coordinated Time (UTC) Date reported by the GPS.
UTC Time
The current Universal Coordinated Time (UTC) Time reported by the GPS.
Latitude
The current Latitude reported by the GPS.
Longitude
The current Longitude reported by the GPS.
Altitude
The current Altitude above sea level reported by the GPS.
Heading
The current heading reported by the GPS.
Note: This value is computed by movement, not vehicle orientation.
Site
When configured, will report the site name and distance from the current position.
MODBUS DEVICE 01 DIAGNOSTICS
Device Name: Device 01
Adjust Configuration
Command: READ 32-bit
Register#: 12000
Write Value: 0
Send Command_____________________________
Connection: Closed
Sent Command: READ 32-bit
FN Reg# #of Regs
[0x03][0x2EE0][0x0002]
Received: Value = 65535
FN Bytes Value
[0x03][0x04][0x0000FFFF]
Next Prev Exit Enter
D I A G N O S T I C S M E N U
UTC Date: 15/9/08 UTC Time: 18:11:52
Latitude: 28 41.655 N
Longitude: 081 21.112 W
Altitude: 52.8 M
Speed: 0.0(MPH) 0.0(KPH)
Heading: 104
Site: Toptech 27 M
Prn: 19 7 13 27 3 23 11 6 8 28 16 51
Rx: 22 28 36 26 13 39 23 22 20 19 14 27
Fix: ** ** ** ** ** ** ** **
Next Prev Exit Enter
