Firmware Version 3/4.31.37
2.10 NAVIGATING THE SYSTEM:
The following describes how to navigate the system, select field values, perform data entry, and toggle options
on and off.
Note: All unknown or not allowed sequences of switch or key actuations are rejected and have no
impact on the software or measurement data.
2.10.1 MENUS AND SCREENS
The MultiLoad II Main Menu is shown below. From this menu, you can select one of four main functions.
The reverse video highlight bar indicates the current selection. Press Next to select Diagnostics, and then press
the Enter key to go to the Diagnostics Menu.
For menu options and function screen items, pressing the Next key moves the selection bar down, and pressing
the Prev (Previous) key moves the selection bar up.
To return to the Main Menu, press Exit. To return to any previous screen, press the Exit key.
Note: Depending on the card-reader mode the Card Reader Screen could appear as iButton Reader.
