c) Press the number that corresponds to Pump Run. This should stop the pump. Depending on the site
configuration, it may be necessary to close the component block valve. If appropriate, press the number
that corresponds to Opn Blk Val.
d) Press Exit until the MultiLoad II re-boots (exit program mode).
Note: If you re-boot (exit program mode) without stopping the pump or closing the block valve, these devices will
automatically de-energize.
8.20 COMPONENT DIAGNOSTICS
Component diagnostics enable your technician or electrician to diagnose wiring problems or hardware problems
by testing the wiring and control from the MultiLoad II to outside devices such as block valves, pump runs/status,
and permissives.
- Input statuses can be viewed as ON or OFF.
- Outputs can be activated or deactivated from this screen by pressing the number that corresponds to the
function.
1. From the Diagnostics Menu, select Components.
2. After Selection of the Component, the Component Diagnostics screen displays. Only the I/O that is
configured will appear on this screen.
To Next Page
