Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
258
Firmware Version 3/4.31.37
8.15 RCU DIAGNOSTICS
The RCU Diagnostics screen displays the state of the MultiLoad II Program switch, the Weights and Measures
switches.
1. From the Diagnostics Menu, select RCU.
2. The RCU Diagnostics screen displays:
 The newest Hardware (CPU board rev 2.1) will show the battery voltage, internal temperature, and
remaining battery capacity.
Security Bypass
ON means that the Security Bypass functionality has been enabled and the dip
switch currently to right (direction opposite the ribbon cable).
OFF means that it has been disabled and that the dip switch is to the left
(direction towards the ribbon cable).
RCU DIAGNOSTICS
Security Bypass-ON
Program Key -ON
W&M Key -ON
Battery @ 25C 3.30V
Battery 100%
Pwr 05/04/15 8:20
Pgm 05/04/15 8:20
Exit
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
