Toptech Systems MultiLoad II User Manual

Chapter 4 – General Configuration
121
Firmware Version 3/4.31.37
Parameter
Description
Alarm High API Gravity
When an API Gravity Sensor is enabled, this parameter can be used to raise an alarm
when the measured API Gravity rises above a maximum value. When the API Gravity
of the metered product exceeds the value entered in this field, an API Gravity alarm
will be raised and loading will be stopped. See API Gravity Calibration for instructions
on configuring an API Gravity sensor.
API Gravity Alarm Time
At the default value of zero seconds, API Gravity alarms will be raised instantly. A
small delay can be added, in seconds, to avoid nuisance alarms that may occur when
API Gravity is momentarily out of range. The API Gravity alarm timer will only run
when an API Gravity alarm is not active and a batch is currently authorized on this
preset.
API Gravity @ Low
Value
Enter the API Gravity that will represent the lowest API Gravity value measured by the
transmitter. This value will be equal to 4 mA or 1V.
API Gravity @ High
Value
Enter the API Gravity that will represent the highest API Gravity value measured by
the transmitter. This value will be equal to 20 mA or 5V.
API Gravity Offset
This parameter provides a means to introduce an API Gravity offset to correct the
indicated API Gravity to the observed API Gravity.
4.8.4 COMPONENT SETUP
Use the Component Setup functions to configure the characteristics of a component.
Further details about flow control can be found in Chapter 5.
Component flow rates are configured in the Weights & Measures -> Component section and can be found in
Chapter 8.
Navigate to this screen as: Program Mode -> Configuration -> Equipment Setup -> Select Parameter Level ->
Components
The Component Setup screen displays:
Parameter
Action
Meter #
Assign the component to a flow meter.
High Flow Rate
Set to the same value as the high flow rate in the preset menu. It may be a different
value if piping requirements dictate.
PRE #1 CMP #1 (Base 001 ) SETUP
Meter#: 1
High Flow Rate: 600
1st Stage Trip Vol: 70
1st Stage Flow Rate: 225
2nd Stage Trip Vol: 20
2nd Stage Flow Rate: 150
Final Trip Vol: 1.15
Final Trip Max Time: 5.000
Final Trip Vol Lock: DISABLD
Unauth Flow Alrm Vol: 10
W&M Recipe Percentage: %0.00
BlkValve Open Rate: 0
BlkValve Open Delay: 0
B.V. Open Alrm Time: 10
Next Prev Exit Enter
