Toptech Systems MultiLoad II User Manual

Chapter 2 –System Description
18
Firmware Version 3/4.31.37
2.2 SYSTEM OVERVIEW
The MultiLoad II is designed to manage multiple loading arms delivering straight or blended products. The
system can operate in conjunction with the Toptech TMS system (remote processing mode), in Local
(standalone) mode or connected to the cloud (UAP Mode). The MultiLoad II supports:
 12 loading arms
 5 meters per loading arm, 6 component ratio blending.
 8 components per loading arm, 8 components sequential blending.
 Sequential, Ratio and Side-stream blending.(proportional as non-proportional blending)
 Watercut calculation
 16 additive injectors per loading arm
 4 samplers per loading arm
 Digital, two stage, and Analog 4-20mA control valves
 RTD temperature inputs
 4-20 ma input for either density, relative density, api gravity, pressure , bsw or watercut
 Ethernet communications
 Ethernet printing
MultiLoad II Single Meter Preset (SMP) is an economical package, designed to support single load arm/single
meter applications. The system can operate in conjunction with the Toptech TMS system (remote processing
mode) , in Local (standalone) Mode or in UAP (TDS) Mode. The MultiLoad II SMP supports:
 1 loading arm
 1 meter
 8 components (different meter factors for each product)
 No blending and no watercut.
 2 additive injectors
 4 samplers per loading arm
 Digital, two stage, and Analog 4-20mA control valves
 RTD temperature input
 4-20 ma input for either density, relative density, api gravity, pressure or bsw
 Ethernet communications
 Ethernet printing
MultiLoad II Skid Control System (SCS) is an economical package, designed to support LACT skid meter
applications. The system can operate in conjunction with the Toptech TMS system (remote processing mode), in
Local (standalone) Mode or in UAP (TDS) Mode. The MultiLoad II SCS supports:
 1 loading arm
 4 meter
 8 components (different meter factors for each product)
 No blending, only Watercut.
 20 samplers per loading arm
 10 Tanks
 Digital, two stage, and Analog 4-20mA control valves
 RTD temperature input
