Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
261
Firmware Version 3/4.31.37
8.18 METER DIAGNOSTICS
Meter diagnostics enable your technician or electrician to diagnose wiring problems or hardware problems by
testing the wiring and control from the MultiLoad II to outside devices such as digital control valves, flow meters,
and permissives.
- Input statuses can be viewed as ON or OFF.
- Outputs can be activated or deactivated from this screen by pressing the number that corresponds to the
function.
1. From the Diagnostics Menu, select Meters.
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
PRE #1 (Preset 001) DIAGNOSTICS
Permissive -OFF
[1]PermissOut -ON
[2]Authorized -OFF
[3]Alarm Out -ON
Meter Stop -OFF
Remote Start-OFF
[4]Batch Auth -OFF
[5]Flow Active -OFF
[6]Opn Bk Val -OFF
[7]Cls Bk Val -ON
Bk Val Status-OFF
[8]OutPulse - 20
Exit
