Firmware Version 3/4.31.37
In the RCU, Trace, Bay, Preset, Component, Meter and Additives setup screens, parameters that are highlighted
in YELLOW indicate values that have been modified from the factory default value.
2.11 SWITCH ACCESS CONTROL
MultiLoad II supports external access control switches. This switches limit access to Program Mode and
changes to Weights and Measures controlled parameters (Values displayed in red).
There are three types of external switches and all can be sealed and/or locked to prevent access to Program
Mode and prevent changes to Weights and Measures controlled parameters.
In Program Mode the operator has access to the following:
- The Configuration Menu parameters
- The Diagnostics Menu and its functions
- Other administrative procedures, such as clearing high-level alarms.
To access Program Mode, the MultiLoad II terminal operator must:
1. Move the Program Mode switch into the active position.
2. At the idle card in screen, enter the security code (default security code is 000000) and press the <Next>
key.
Your local Weights and Measures office may need to be contacted after breaking the seal and changing
parameters. This is typically done only during meter proving or temperature calibration.
RCU SETUP
Preset Slct Timeout: 0
Pixel Test: DISABLD
Meter Proving Mode: DISABLD
W&M Key FCM#: DISABLD
Program Key FCM#: DISABLD
Startup Keypad Locked: DISABLD
RCU Address: 001
Next Prev Exit Enter
