Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
242
Firmware Version 3/4.31.37
CHAPTER 8 DIAGNOSTICS
8.1 OVERVIEW
The MultiLoad II provides built-in diagnostic tools that enable your technician(s) or electrician(s) to isolate wiring
or hardware problems by performing various tests. The main diagnostic functions available from the Diagnostics
Menu and described in this chapter are:
Card Reader
(Excluding SMP)
Tests the prox card reader.
COM Loopback
Tests communication ports to and from the host system (TMS)
Network Test
Tests network connection to and from the host system (TMS)
Keypad
Tests the individual keys on the keypad
Display
Tests display operation
Unicode
Tests display fonts
FCM Com
Reports communication status with the I/O board and FCMs
PCM Com
Reports communication status with PCMs
FCM Health
Reports the number of timeouts and lost communication events with the I/O board and FCMs.
PCM Health
Reports the number of timeouts and lost communication events with PCMs.
RCU
View/modify RCU level I/O including the Program and W&M key switch status.
Bay
View/modify Bay level I/O.
Preset
View/modify Preset level I/O.
Meters
View/modify Meter level I/O.
Components
View/modify Component level I/O.
Additives
View/modify Additive level I/O.
Sampler
View/modify Sampler level I/O.
Tanks (SCS Only)
View/modify Tank level I/O.
Custom Logic
Tests the custom logic execution.
GPS
Displays the current detailed status of the GPS.
These functions are discussed in the order they appear on the Diagnostics menu.
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode Modbus Device
FCM Com Thread Info
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
