Toptech Systems MultiLoad II User Manual

Chapter 4 – General Configuration
96
Firmware Version 3/4.31.37
DC Input
Port 9
Ground input
DC Output
Port 10
DC Output
Port 11
DC Output
Port 12
4.8.1 BAY SETUP
Use the Bay Setup functions to configure all Bay level configurations.
Navigate to this screen as: Program Mode -> Configuration -> Equipment Setup -> Select Parameter Level -> Bay
Setup
All Weights and Measures controlled values are displayed in red both on the screen and in this manual.
The Bay Setup screen displays:
Parameter
Description
Number Bay Presets
(Excluding SMP & SCS)
Enter the number of presets (load arms) that will be controlled by this MultiLoad II.
Number of FCMs
Enter the number of Flow Control Modules (FCM) including the I/O board that will be
attached to this bay. The maximum number of FCMs that can be attached to a bay is 32 (1
on MultiLoad II SMP).
Number of PCMs
(Excluding SCS)
Enter the number of Printer Control Modules (PCM) that will be attached to this bay.
Temperature UOM
This selection indicates whether temperatures will be in Fahrenheit or Celsius. Select
“F” to choose Fahrenheit or “C” to choose Celsius.
Canada API Limits
When enabled, API tables will use extended temperature ranges as required by
Measurement Canada.
Number of Tanks
(SCS Only)
Enter the number of Tanks that are connected to the MultiLoad.
BAY SETUP
Number Bay Presets: 1
Number of FCMs: 1
Number of PCMs: 0
Temperature UOM: C
Canada API Limits: DISABLD
Number of Tanks: 0
Start Transaction FCM#: DISABLD
Stop Transaction FCM#: DISABLD
Bay Number: 0
Number External Presets: 0
Output Pulse FCM#: 0
Output Pulse Factor: 10.000
Deadman Mode: NONE
Input Deadman FCM#: DISABLD
Next Prev Exit Enter
