Chapter 6 – Additive Control
Firmware Version 3/4.31.37
The new additive meter factor is now in effect.
16. Press EXIT to exit to the Select Additive screen.
All additive volumes delivered during the calibration process will be added to the Unauthorized
Totalizer of the additive under test.
6.7.3 PISTON TYPE ADDITIVE CALIBRATION
As noted previously, the calibration screens for Piston type injectors are slightly different than the screens used
for additive flow meter injectors. The procedure, however, is identical.
PRE #1 ADTV #1 (Adtv 001 ) CALIBRATE
Press Next Key to Inject Now!
Injection: 0
Piston Cycles: 0
Delivered Volume: 0.000( 0cc)
Exit
PRE #1 ADTV #1 (Adtv 001 ) CALIBRATE
Automatic Calibration Function
Review Last Calibration Data
Calculate Additive Vol/Inject
Additive Vol/Inject: 0.0200
Additive Mtr K-Factr: 2600
Additive Mtr Factor: 1.0658
Next Prev Exit Enter
To Next Page
