Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
363
Firmware Version 3/4.31.37
CHAPTER 12 OPERATION
12.1 OVERVIEW
This chapter discusses the two methods of MultiLoad II operation: Remote Control and Local Control.
Under Remote Control, the MultiLoad II relies on TMS to handle all driver data entry tasks and product
authorization.
Under Local Control, the MultiLoad II handles driver data entry tasks and data validation via internal configuration
and stored validation lists.
On MultiLoad II On MultiLoad II SMP
(1/100 resolution is displayed when the Use Hundredths RCU W&M parameter is enabled)
12.2 PHASES OF OPERATION
There are four main phases of MultiLoad II operation:
Phase 1 – Authorization
Phase 2 – Preset
Phase 3 – Loading
Phase 4 – End Load
12.3 DRIVER CARD OR KEYPAD ACCESS
To begin the authorization process, the MultiLoad II RCU will read a driver’s Prox Card (Excluding the SMP) or
will prompt the driver to enter an access ID. Next the driver will be prompted to enter a PIN code.
Preset 001
IDLE
PRESET:
0
DELIVER:
0
GALLONS
ExitLoad Enter=Preset
PRE PRODUCT SET DEL STATUS
>1 Preset 001 0 0 IDLE
2 Preset 002 0 0 IDLE
Next Prev ExitLoad Enter=Pick
