8.17 PRESET DIAGNOSTICS
Preset diagnostics enable your technician or electrician to narrow down the problem by showing what is turned on
or off.
- Input statuses can be viewed as ON or OFF.
- Outputs can be activated or deactivated from this screen by pressing the number that corresponds to the
function.
1. From the Diagnostics Menu, select Preset.
2. The Preset Diagnostics screen displays: Only the I/O that is configured will appear on this screen.
D I A G N O S T I C S M E N U
Card Reader Meters
COM Loopback Components
Serial Ports Additives
Network Test Sampler
Keypad Tanks
Display Custom Logic
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev Exit Enter
BAY DIAGNOSTICS
*GROUND -OFF
*VRU -OFF
*OVERFILL -OFF
*ESD PERM -OFF
*BAY PERM4 -OFF
*BAY PERM5 -OFF
*BAY PERM6 -OFF
*BAY PERM7 -OFF
[1]PermissOut -OFF
[2]Authorized -OFF
[3]Alarm Out -OFF
[4]OutPulse - 20
Exit
