ARM CoreLink GIC-600AE User Manual

Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Programmers model
Offset Name Type Reset Width Description Architecture
defined?
0x0E00-
0x0EFC
GICD_NSACRn
3
RW 0x0 32 Non-secure Access Control Registers, n = 0-63, but
n=0-1 are Reserved when affinity routing is enabled
Yes
0x0F00-
0x5FFC
- - - - Reserved -
0x6000-
0x7FF8
GICD_IROUTERn RW 0x0080000000 64 Interrupt Routing Registers, n = 0-991, but n=0-31 are
Reserved when affinity routing is enabled.
See the GICv3 and GICv4 Software Overview.
All SPIs are reset with Interrupt_Routing_Mode == 1.
The first register is GICD_IROUTER32.
Yes
0xC000 GICD_CHIPSR RO P-Channel
dependent
32 Chip Status Register. Reserved in single-chip
configurations.
No
0xC004 GICD_DCHIPR RW 0x0 32 Default Chip Register. Reserved in single-chip
configurations.
No
0xC008-
0xC080
GICD_CHIPRn RW 0x0 64 Chip Registers, n = 0-15. Reserved in single-chip
configurations.
No
0xC088-
0xDFFC
- - - - Reserved -
0xE000-
0xE0FC
GICD_ICLARn RW 0x0 32 Interrupt Class Registers, n = 0-63, but n=0-1 are
Reserved
No
0xE100-
0xE17C
GICD_ICERRRn RW 0x0 32 Interrupt Clear Error Registers, n = 0-31, but n=0 is
Reserved
No
0xE180-
0xEFFC
- - - - Reserved -
0xF000 GICD_CFGID RO Configuration
dependent
64 Configuration ID Register No
0xF008-
0xFFCC
- - - - Reserved -
0xFFD0 GICD_PIDR4 RO 0x44 32 Peripheral ID 4 Register No
0xFFD4 GICD_PIDR5 RO 0x00 32 Peripheral ID 5 Register No
0xFFD8 GICD_PIDR6 RO 0x00 32 Peripheral ID 6 Register No
0xFFDC GICD_PIDR7 RO 0x00 32 Peripheral ID 7 Register No
0xFFE0 GICD_PIDR0 RO 0x92 32 Peripheral ID 0 Register No
0xFFE4 GICD_PIDR1 RO 0xB4 32 Peripheral ID 1 Register No
0xFFE8 GICD_PIDR2 RO 0x3B 32 Peripheral ID 2 Register No
0xFFEC GICD_PIDR3 RO 0x00 32 Peripheral ID 3 Register No
0xFFF0 GICD_CIDR0 RO 0x0D 32 Component ID 0 Register No
0xFFF4 GICD_CIDR1 RO 0xF0 32 Component ID 1 Register No
0xFFF8 GICD_CIDR2 RO 0x05 32 Component ID 2 Register No
0xFFFC GICD_CIDR3 RO 0xB1 32 Component ID 3 Register No
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 100 of 268
