Programmers model
Table 5-51: GICT_ERR<n>MISC0.Data field encoding
Record GICT_ERR<n>STATUS.IERR (syndrome) GICT_ERR<n>STATUS
.SERR
Value and description of
GICT_ERR<n>MISC0.Data (other bits
RES0)
Always packed from 0 (lowest = 0)
Software error
(0)
0x0, SYN_ACE_BAD
Illegal ACE-Lite subordinate access.
0xE AccessRnW, bit[12]
AccessSparse, bit[11]
AccessSize, bits[10:8]
AccessLength, bits[7:0]
Software error
(0)
0x1, SYN_PPI_PWRDWN
Attempt to access a powered down Redistributor.
0xF Redistributor, bits[24:16]
Core, bits[8:0]
Software error
(0)
0x2, SYN_PPI_PWRCHANGE
Attempt to power down Redistributor rejected.
0xF Redistributor, bits[24:16]
Core, bits[8:0]
Software error
(0)
0x3, SYN_GICR_ARE
Attempt to access GICR or GICD registers in mode that
cannot work.
0xF Core, bits[8:0]
Software error
(0)
0x4, SYN_PROPBASE_ACC
Attempt to reprogram PROPBASE registers to a value
that is not accepted because another value is already in
use.
0xF Core, bits[8:0]
Software error
(0)
0x5, SYN_PENDBASE_ACC
Attempt to reprogram PENDBASE registers to a value
that is not accepted because another value is already in
use.
0xF Core, bits[8:0]
Software error
(0)
0x6, SYN_LPI_CLR
Attempt to reprogram ENABLE_LPI when not enabled
and not asleep.
0xF Core, bits[8:0]
Software error
(0)
0x7, SYN_WAKER_CHANGE
Attempt to change GICR_WAKER abandoned due to
handshake rules.
0xF Core, bits[8:0]
Software error
(0)
0x8, SYN_SLEEP_FAIL
Attempt to put GIC to sleep failed because cores are
not fully asleep.
0xF Core, bits[8:0]
Software error
(0)
0x9, SYN_PGE_ON_QUIESCE
Core put to sleep before its Group enables were
cleared.
0xF Core, bits[8:0]
Software error
(0)
0xA, SYN_GICD_CTLR
Attempt to update GICD_CTLR was prevented due to
RWP or Group enable restrictions.
0xF Data, bits[7:0]
Software error
(0)
0x10, SYN_SGI_NO_TGT
SGI sent with no valid destinations.
0xE Core, bits[8:0]
Software error
(0)
0x11, SYN_SGI_CORRUPTED
SGI corrupted without effect.
0x6 Core, bits[8:0]
Software error
(0)
0x12, SYN_GICR_CORRUPTED
Data was read from GICR register space that
encountered an uncorrectable error.
0x6 GICT_ERR0ADDR is populated
Software error
(0)
0x13, SYN_GICD_CORRUPTED
Data was read from GICD register space that
encountered an uncorrectable error.
0x6 GICT_ERR0ADDR is populated
