Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Electrical Power
Page 220
E4.08.04
Rev.29
24-30-00
01-Jul-2020
J. Mark the inspected Alternator E4A-91-000-000
For each check of the ASSY brush holder E4A-91-300-000, engrave an X (cross) on the bottom of the
alternator. Fig. 24 - 25 shows the dimension of the marking.
Fig. 24 - 26 Alternator bottom side with marking
To increase the visibility of the cross, you can additionally mark with a permanent marker.
Do not use stickers for marking!
~10 mm
~10 mm
X (Cross)
Fig. 24 - 25 Dimension of marking
